Red: wave length: 625~630nm;1100-1300mcd
Green: wave length: 525~530nm;1900-2400mcd
Blue: wave length: 470~475nm;500-700mcd
Calibrated brightness proportion ratio
R: G: B = 30%:60%:10%
100 grade auto/manual-adjustment
View angle(degree)(50% brightness)
Horizontal: 120° (60° off center); Vertical: 70° (+25°/-45° off center)
Readability viewing angle
Horizontal: 150° (75° off center); Vertical: 90° (+35°/-55° off center)
DVI interface(DVI connector)
VGA, Video, AVI, MOV, MPG, DAT, VOB etc.
IP65 front side/IP54 backside
Signal transmission direction
Operating temperature(Celsius degree)
Storage temperature(Celsius degree)
Front and back serving optional
Synchronous & asynchronous available
Wire Ethernet, Fiber Ethernet,RF wireless,GPRS
120/240 V AC single phase(50-60Hz)
Maximum power consumption(W/SQM)
Average power consumption(W/SQM)
Screen operation mode(scan/static)
Module configuration(Pixels quantities of the module)
PH6mm Outdoor full color LED display is smallest pixel of RGB DIP outdoor LED Display. It can be assembled, disassembled and repaired very easy. Wide application field: advertising LED display, stadium perimeter LED display, mobile led display for mobile media, shopping mall LED display for logo showing, bank & stock exchange LED display for rates showing, stage performances and so on.
Features & Technical Specification:
1. Wide application field: advertising LED display, stadium perimeter LED display, mobile led display for mobile media, shopping mall LED display for logo showing, bank & stock exchange LED display for rates showing, train & bus station, airport, telecommunication LED screen system for information showing and instruction, stage performances and so on.
2. High Contrast and Frequency: 4000:1 and 5000HZ, which is a very high level to ensure a vivid image of our LED screen system.
3. Good quality LED chip: Supplied by Nichia, Cotco cree,Toyota,Silan.Optec,& other high strictly selected LED chip to ensure the long life time and high brightness of our LED screen system.
4. Very high quality and Clear vivid image quality: even in direct, full-on sunlight to ensure you attracts more audience to get short ROI of your LED screen's investment.
5. High Brightness of LED Display: 7500-nit brightness(for outdoor full color)(more than 2000 nits brightness for indoor full color) capacity throughout product lifetime of the LED display.
6. Easy Installation & Using : easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED screen system.
7. Convenient Servicing: Front or rear led display cabinet access make the maintains work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
